Product Description
Pipishell - Make Your Life Better!
PIAT2- Our whole new advanced full tilt wall mount is designed with great flexibility for convenient space saving and increase your viewing experience. It's easy to install onto your wall and supports TVs 50"-90" in size. You will fancy and you will also in luck: This tilt mount's extendable design is perfect for getting the best viewing angle when mounting above the mantel and mount extension means easy cable access.
Will it fit my TV?
- First, please check your wall for wood studs. Of course! It can be mounted on concrete wall and brick wall, but you need to use additional anchors when installing. Please pay attention to the wall mounting studs distance is 24 inch maximum.
- Next, the weight of your TV should be less than 165lbs/75kg and your TV should be at least 50 inch.
- Then, please check the VESA pattern, VESA = horizontal × vertical. Mounting holes distance on the back of TV must be less than 24" (600mm) horizontally and 16" (400mm) vertically.
- Finally, please check the TV back area inside the 4 mounting holes to make sure there are not any cables outlet. Otherwise, the plate may block the plugs.
Specifications:
- Unique Universal design fits OLED, LED, LCD, Curved, Plasma, Flat large TVs from 50-90” including the most TV sizes 90"/85"/80"/75"/70"/65"/60"/55" and 50", supports TV weight up to 165lbs/75kg.
- Supports all major television brands including Samsung, LG, Sceptre, Sony, Vizio, Toshiba, Philips, Sharp, Panasonic, Insignia, Hisense, TCL, Sceptre, JVC, Avera and Others.
- Fits VESA mounting hole patterns: 600x400/600x200/500x300/400x400/400x300/400x200/300x300/300x200/200x200/200x100mm ( In inches: 24"x16"/24"x8"/20"x12"/16"x16"/16"x12"/16"x8"/12"x12"/12"x8"/8"x8"/8"x4").
- Convenient remove and lock with drawstring and the easy-grip knobs allow tool less tilt and lock. Also can mount to stud walls. Universal brick and concrete with included anchors.
Package includes:
1x TV wall mount / 1x Standard mounting hardware / 1x Wall Drilling Template / 1x User manual
 |
 |
 |
 |
 |
 |
|
|---|---|---|---|---|---|---|
| PILFK1 | PIMFK1 | PIMF2 | PIMTK1 | PILTK4 | PIAT2 | |
| Mount Type | Full Motion TV Mount | Full Motion TV Mount | Full Motion TV Mount | Tilt TV Mount | Lrage Tilt TV Mount | Tilt Extension TV Mount |
| TV Size | 37-70" | 26-55" | 13-55" | 26-55" | 37-70" | 50-90" |
| Max Load | 132 LBS | 99 LBS | 66 LBS | 99 LBS | 132 LBS | 165 LBS |
| Max VESA | 600x400mm | 400x400mm | 400x400mm | 400x400mm | 600x400mm | 600x400mm |
| Tilt Angle | +10°/-10° | +5°/-12° | +5°/-15° | +0°/-8° | +0°/-7° | +8°/-8° |
| Swivel Angle | ±60° | ±45° | ±90° | |||
| Distance to Wall | 3"-15.4" | 3.2"-14.9" | 2.2"-17" | 1.3" Low Profile | 1.5" Low Profile | 2.4"-5.2" |
| Fitting Studs Spacing | up to 16" | up to 16" | Single Wood Stud | up to 16" | up to 24" | up to 24" |
